Fully-auto Film Wrapping Equipment Manufacturers

Fully-auto Film Wrapping Equipment Manufacturer and Line Integrator

Shanghai KUKO Packing Machinery Co., Ltd. has designed and manufactured fully automatic film wrapping and heat shrink packaging equipment since 2004. Our Fully-auto Film Wrapping Equipment Manufacturer range covers low-, medium- and high-speed series with more than 200 models, engineered for continuous 24/7 production and MES connectivity. We are a China-based manufacturer serving food, daily chemicals, electronics, logistics, pharmaceutical and furniture producers in more than 160 global markets.

We build the core technology in-house: PTFE-coated sealing blades, constant-temperature shrink tunnels, precision film feeding and PLC-based controls. This lets us deliver a single compact machine or a complete end-of-line wrapping system with consistent engineering and one point of responsibility.

Product Range and Application Fit

Our equipment is organized by sealing principle, production format and throughput target. Each product type addresses a different packaging geometry.

For ultra-small, lightweight products, the Fully-auto Static Sealing Shrink Wrapping Machine combines electrostatic sealing with a mini thermostatic tunnel. It packages items from 100×100×10 mm to 250×250×100 mm, with a compact footprint for small workshops, e-commerce packing stations and live-stream packaging operations.

Application Fit by Industry

• Food and beverage: tray and carton multi-packs, promotional bundles, dust- and moisture-resistant transparent wrapping.
• Daily chemicals and personal care: round, square and irregular containers, gift sets and combos using sleeve sealing or shrink wrapping.
• Electronics and 3C: anti-scratch surface protection and dust isolation for components, accessories and finished devices.
• Pharmaceuticals: sealed medicine boxes, leaflet and sample bundling, with integration to batch reporting systems.
• Logistics and e-commerce: multi-item order consolidation, carton protection and tamper-evident wrapping.
• Home and building materials: larger-format parts, profiles and panels wrapped with PE or shrink film for safe handling.

Engineering and Configuration Approach

We configure each machine around the product dimensions, required output and film type. In the static sealing range, for example, the GH-300SJ and SF-4020G models package items from 100×100×10 mm up to 250×250×100 mm with POF film; the SF-4020G adds a larger thermostatic tunnel for higher throughput. Sealing temperature, tunnel temperature, conveyor speed and sealing dwell time are adjusted together to avoid common shrink defects such as hazing, fish eyes, dog ears and weak seals.

• PTFE/Teflon non-stick sealing blades produce clean, smooth seals without charring or sticking.
• Precision film feeding with limit-switch control reduces film consumption in mass production.
• Independent constant-temperature tunnels with uniform hot-air circulation ensure a transparent finish on POF film.
• Fault alarms and overload shutdown protection are standard on the complete range.
• Working height is typically 850 ± 25 mm to match operator ergonomics and existing conveying.

The Fully-auto Sealing and Shrink Wrapping Machine series adds side sealers, corner sealers and mix-production configurations for plants that run multiple format families on one line.

Controls, Automation and MES Integration

Our machines use programmable logic controller (PLC) based controls with HMI panels for temperature, speed and dwell-time adjustment. The control system is prepared for MES integration so that cycle counts, fault events and equipment status can be delivered to the plant's production information system.

For end-of-line projects, we integrate the wrapper with product feeding conveyors, collation guides and downstream case packing or palletizing equipment. The same engineering team designs the wrapper and the line interface, so compatibility is confirmed before shipment.

For bottle and container lines, the Sleeve Sealing Shrink Wrapping Machine range provides column-type, integral and multi-layer configurations to match line speed and bundle pattern.

Quality Assurance and Acceptance

We manufacture at two production bases in Kunshan Zhouzhuang Industrial Park and Shanghai Sheshan Industrial Park, with a total workshop area of 34,000 m². German IPG laser cutting and imported servo bending equipment provide consistent sheet metal accuracy for machine frames and guarding.

We hold ISO 9001 and ISO 14001 certification, EU CE certificates for the shrink packaging machine and conveyor, recognition as a Shanghai High-Tech Enterprise and a “Specialized and Sophisticated” Enterprise, and a portfolio of invention and utility model patents. Each machine is test-run and adjusted before shipment; acceptance at installation is based on the agreed output rate and final packaging finish.

Installation, Maintenance and Spare Parts

Machines are delivered with export packaging and documentation covering installation, operation, maintenance and troubleshooting. We provide technical support for installation and startup on overseas projects, and spare parts such as sealing blades, heating elements, temperature sensors, fans and conveyor components are available by machine model.

Every machine carries a one-year free warranty and lifetime maintenance support. The film path, sealing bar, temperature probes and conveyor components are arranged for accessible maintenance and quick changeover.

Information We Use to Configure Your Solution

Send us the following project details and we will prepare a machine configuration, layout drawing and quotation.

• Product shape, dimensions (L × W × H), weight and whether the product is rigid or unstable
• Film type (POF, PE, PVC) and thickness, if already specified
• Required throughput in packs per minute and the shift pattern (24/7 or seasonal)
• Number of product formats and expected changeover frequency
• Infeed arrangement: manual, conveyor, or direct connection to upstream equipment
• Utility conditions: AC 220 V or 380 V, 50/60 Hz, single- or three-phase
• Space constraints and any requirement for MES connectivity or full line integration

Frequently Asked Questions

What is the difference between static sealing and conventional heat sealing?

Static sealing uses electrostatic adhesion on the overlap of a single-layer film, creating a thin seal that is easy to tear open. Conventional L-bar and side sealing use heated sealing bars to fuse the film into a stronger seal. Static sealing suits ultra-small, lightweight products where convenient opening matters; heat sealing suits higher-speed and heavier packaging.

Which shrink films can the equipment run?

We set the machine parameters according to the film specified in your project. POF is standard for the static sealing and fully closed shrink wrapping series, PE and POF are typical for sleeve sealers, and PE hood or shrink film is used for pallet wrapping. Film selection directly affects sealing temperature, tunnel temperature and conveyor speed, so we confirm it during configuration.

Can the wrapping machine be connected to an existing packaging line?

Yes. We design infeed conveyors, collation guides and discharge sections to match the existing line height and speed. The control system can be interfaced with the plant's PLC or MES for production reporting, fault integration and batch traceability.

How is machine acceptance performed?

Machines are test-run before shipment. At installation, we complete leveling, electrical connection, temperature and speed calibration, and run sample products to verify seal quality and shrink finish. Acceptance is based on the mutually agreed output per minute and final packaging appearance.

What after-sales support is available?

All equipment includes a one-year free warranty and lifetime maintenance support. Our team can supply spare parts such as sealing blades, Teflon cloth, heating elements, temperature sensors and conveyor spares, and provide technical support for control system settings on MES-connected machines.
