Fully-auto Motion Side Sealer and Shrink Tunnel

This fully-auto Motion Side Sealer and Shrink Tunnel integrates a high-speed side sealing and cutting unit with a heat-shrink tunnel, making it an all-in-one packaging device designed for high-volume production lines. The equipment automates the entire process from feeding and sealing to heat shrinking, creating a neat and precise packaging appearance while providing comprehensive product protection. The fully automatic operation mode effectively reduces manual labor, maintaining consistent and stable packaging quality throughout the process, making it suitable for high-volume continuous production scenarios.

Product Details Technical Specifications Feedback

Key Features:

One-button debugging: Simply input the actual product dimensions to complete equipment debugging, significantly lowering the operational threshold and saving time and effort during production changeovers.

High-speed continuous sealing and cutting: Supports uninterrupted sealing operations by the side blades, with a maximum capacity of up to 80 pieces/minute. Its outstanding operating speed fully meets the demands of high-cycle production.

Linked horizontal sealing structure: The horizontal sealing blade adopts a reciprocating motion design, allowing for precise linkage with product conveying, perfectly adapting to uninterrupted continuous production modes.

Diverse Feeding Configurations: The front-end conveying equipment can be equipped with finger conveyors or intelligent sorting conveyors as needed, adapting to products of different shapes and specifications to be packaged.

High-End Servo Control System: The cross-cutting mechanism is equipped with a servo motor and a professional motion controller, supporting multi-axis interpolation and continuous interpolation functions, ensuring precise and reliable operation while maintaining high-speed operation.

High-Quality Core Components: The entire machine uses components from well-known international brands. The control system, sensors, pneumatics, and transmission components have excellent performance, resulting in a low failure rate and stable, durable long-term continuous operation.

Precise Temperature-Controlled Shrink Tunnel: The shrink chamber has precise temperature control, allowing the heat-shrink film to tightly adhere to the product, providing dustproof, moisture-proof, and friction-resistant protection.

Flexible Adaptability: The equipment can be flexibly adjusted according to product specifications, adapting to the packaging of various small products within its range, offering strong versatility.

Safety Protection Design: The entire machine is equipped with comprehensive safety protection components, standardizing equipment operation, ensuring operator safety, and effectively extending the equipment's service life.

Applications: Widely used in the bulk packaging of food, beverages, pharmaceuticals, cosmetics, small electronic products, books, daily necessities, and various small industrial parts. It is especially suitable for high-speed automated packaging of various small boxed, bagged, bottled single items and combination goods, and is an ideal packaging equipment for high-capacity production lines in various industries.

Parameter Model GH-3015CM Model SF-5030LG
Power 7.5Kw 21Kw
Power Supply AC 220V 1/3PH 50/60HZ AC 220/380V 3PH 50/60HZ
Packing Size L≤500mm, W≤300mm Chamber Size (L×W×H):
W+H≤450mm, H≤150mm 2000×500×300mm
Cross Blade Length 490mm /
Packing Speed 0~80pcs/min. 0~80pcs/min.
Working Table Height 900 ± 25mm 900 ± 25mm
Shrink Film POF POF
Machine Size (L×W×H) 2935 × 1685 × 1610mm 2935 × 1685 × 1610mm
Export Crate Size (L×W×H) 3035×1785×1810mm 2400×1140×1460mm
Gross / Net Weight 1200/1000kgs 650/570kgs
Why Kuko
Shanghai Kuko Packaging Machinery Co., Ltd.

Founded in 2004 and headquartered in Sheshan Town, Songjiang District, Shanghai, KUKO specializes in fully automatic sleeve sealing & heat shrink packaging machines, offering more than 200 models covering low-speed, medium-speed, and high-speed series to meet different industry and production capacity requirements. We provide complete sleeve sealing and heat shrink packaging solutions. Our machines ensure stable 24-hour continuous operation, support seamless integration with MES systems, and fully comply with international production standards.

To ensure product quality and efficiency, we have introduced advanced equipment, including German IPG high-precision laser cutting machines and imported high-precision servo bending machines. To support our global development, we operate modern production bases in Kunshan Zhouzhuang Industrial Park and Shanghai Sheshan Industrial Zone, with a total workshop area of 34,000 square meters, enabling large-scale and standardized production.

With over 20 years of professional experience, KUKO has been recognized as a Shanghai High-Tech Enterprise and Shanghai Specialized, Sophisticated, Unique & New Enterprise. We hold ISO9001 and EU CE certifications, and own multiple invention and utility model patents.

The company has established long-term stable cooperation with well-known enterprises worldwide, covering food, daily chemicals, electronics, logistics, pharmaceuticals, furniture, and other industries. Committed to reliable quality and professional service, we help customers improve efficiency and reduce costs, providing stable packaging equipment and technical support for global partners.
